PNEUMATIC ACTUATOR Output Torques to 44,130 Lb-in (4,986 N-m)Styling, strength,

compactness, and simplicity of design have been combined to produce the Bray Series 92 direct acting and the Series 93 spring return pneumatic actuators.

Engineeringexcellenceandprecisionmanufacturinghasproduced a modular product line with reduced overall size requirements and economic savings. In addition all Bray accessories are fully modular and directly mount to the actuator – providing flexibility and efficiency at reduced cost.

Bray Series 92/93 actuators are rack and pinion,opposed-piston actuators available in two versions: double acting for rotation of 90°, and spring return for 90°rotation.

All double acting and spring return units are suitable for both on-off and throttling applications. Actuators which can be actuated with other media such as hydraulic oil or water are also available as an option.
