Connection Ends: Flange to ASME B16.1 CL125

Working Pressure: 300PSI 200PSI and 250PSI available upon request

Temperature Range: 0C~80C

Coating: Fusion Bonded Epoxy Coating in accordance with ANSI/AWWA C550

Features:

• Newly advanced design, less operation torgue & abrasion resistance.

• Body & Cover are made of high grade Ductile Iron.

• Disc is designed with an abrasion resistant nylon guide which can help less opening or closing torgue and smooth

During operation：

• Forged stem provide stronger stem operation and less moving parts.

• Disc is covered by high-grade rubber which complies with drinking water.

• High-tech rubber curing with precise geometry dimensions, more resilient & strong

  adhesive to ductile casting.

• The 3 O-ring stem seals are designed to prevent stem leakage and provide

  replacement of the O-ring without

Disassambling of valve from mainline pipes：

• Both inside & outside are coated with epoxy resin powder.

• Manufacturing standard meets BS EN 1074, BS 5163, BS EN 1171.

• F/F (Face to Face) meets the following standard: BS EN558-1.
