Features:

. The valve is made of DI body and DI disc.

. Advanced newly design with dovetail seal design and captured by epoxy on the back, with multiple raised ring to have more contact with disc but less friction during closure.

. The double eccentric design provides less contact area of seal with disc, and less stress at the open position of the disc.

. The disc design with arch shape and thru disc can provide better flow capacity, stronger and less weight

. The shaft and disc connection with tangential pin which can be exchangeable and provide rigid connection.

. The DN 150-500MM use flat disc, and DN 350-1200MM use arch shape disc.

. Epoxy coated interior and exterior.

. Valve design meets or exceeds EN 593.

. Top flange connection meets ISO 5211-1982, and F/F meets EN 558-1 series 14.
